Sinoboom 22M 11,950kg Electric Telescopic Boom Lift

NEW

Sinoboom 22M 11,950kg Electric Telescopic Boom Lift

With a maximum working height of 22M this electric Sinoboom telescopic boom lift is ideal for indoor and outdoor use with extra basket weight of 454kg (restricted) and machine weight of 11950kg

TB20EJ PLUS

Providing excellent reach for high and hard-to-reach places, the TB20EJ PLUS electric telescopic boom has a maximum working height of 22M and horizontal reach of 13.85M at 454kg and 15.4M at 300kg. Being electric powered, it is suitable for indoor and outdoor applications, and with zero emissions is great for confined areas.

The full 360-degree rotation capability allows for efficient and flexible positioning, enhancing productivity and reducing repositioning time. Intuitive control systems with joystick operation make it easy for operators to maneuver the lift precisely and efficiently. This unit is ideal for construction sites and working in indoor areas where zero emissions are required. Useful for maintenance tasks in large industrial facilities including repairs, inspection and installations at elevated heights.

Our knowledgeable support team is always available to assist with any questions or concerns you may have. You can book a demo with one of our access specialists. Genuine spare parts are also available and our specialist technicians can help keep your machine in tip top working condition.

Each elevated work platform comes with an impressive factory warranty backed up with nationwide technical support and genuine spare parts. The comprehensive After Sales Support programme is supported by YR Connect, YR’s cloud-based online solution for maintenance, servicing, warranty and location services to protect against theft. Click here for more information.

Enquire about this product ›

Specifications

Weight	11950kg
Working Height	22M
Platform Capacity (Restricted / Unrestricted)	454 kg / 300kg
Power	48 V, 480 AH (Lead acid battery) / 48 V, 500 AH (Lithium battery)
Horizontal Reach max (Restricted / Unrestricted)	13.85M / 15.4M

Features

Green working environment without noise pollution and meet indoor or emissions-critical site requirements with no emissions.
Battery quality assurance, low failure rate and reduced maintenance costs with battery-power
Extra capacity of 454kg at restricted height and reach
Both the active and inactive states have an oscillating function, allowing work on inclined and uneven ground
3 full-proportional handles beneficial for gradual control of boom lifting, telescoping, turntable rotation and driving speed
Max Working Height 22 m
Max Platform Height 20 m
Max Horizontal Reach (restricted / unrestricted) 13.85 m / 15.4 m
Length-Stowed 9.99 m
Width-Stowed 2.49 m
Height-Stowed 2.79 m
Wheelbase 2.49 m
Ground Clearance 0.39m
Platform Size (L×W×H) 2.44 m×0.91 m×1.1 m
Capacity (Restricted / Unrestricted) 454 kg / 300kg
Max Platform Occupants 3 Persons / 2 Persons
Drive Speed (Stowed) 0～4.8 km/h
Drive Speed (Raised) 0～1.1 km/h
Gradeability 35%
Turntable Rotation 360^o continuous
Platform Rotation 160^o
Tilt Rating 5°
Turning Radius (Inside/Outside) 2.4 m/5.55 m
Turntable tail swing 1.45 m
Max Allowable Side Force 400 N
Max allowable wind speed 12.5 m/s
Tire Spec/Type 355/55D625/foam filled
Drive × Steer 4WD×2WS
Hydraulic Tank Capacity 180L
48 V, 480 AH (Lead acid battery) / 48 V, 500 AH (Lithium battery)
System Voltage 48V DC
4 WD × 2 WS
Hydraulic Platform Levelling
Proportional control with 3 joysticks
Tilt protection system
Non-marking tyres
7-in display screen
Automotive-grade sleeves for all pipes
Max tilt rating to 5^o
White noise alarm
Secondary guarding device
Telematics-ready connector
Battery isolator
Fault diagnosis system
Active oscillating function
2.44 m platform with swinging gate
Weighing system
Half mesh (for platform swinging gate)
160 degree platform rotation
Footswitch
Lithium battery
4-wheel brake

Options & Accessories

AC power to platform
Platform work light
1.83 m work platform
1.45 platform
Glazier kit (for platform with swinging gate)
